Natural Ester Insulating Oil

Name: Natural Ester Insulating Oil
Availability: InStock

EXW

$2.95-3.24 /kg

Wuhan ZD New Materials Co., Ltd.

Located Region:

China

Address:

Room 506, West Tower, China Special Aircraft Research and Development Center, No.1 Zizhu Street, East Lake High-Tech Development Zone, Wuhan City, Hubei Province

Biz Consulting:

02781625553

E-mail:

zhangxuehua@zdoil.cn

Online Contact

Favorite

ZD Vegetable (Natural Ester) Insulating Oil Business

ZD Vegetable (Natural Ester) Insulating Oil is an insulating liquid extracted from seeds or other biological materials and used in related transformers or similar electrical equipment. Its main component is triglyceride, which has good biodegradability and environmental compatibility.

Product Models

	Soybean-based	Rapeseed-based	Waste edible oil-based	Other oil-based
Vegetable Insulating Liquid	VS100	VR100	VW100	VO100
Vegetable Insulating Liquid (Upgraded Model)	VS200	VR200	VW200	VO200
Notes: VS: Soybean-based, standards comprehensively support the most mainstream oil base VR: Rapeseed-based VW: Waste edible oil raw materials, such as gutter oil, recycled oil, etc. VO: Other oil types, customized according to customer needs

※ZD products have passed FM, UL and other fire protection certifications, SGC and other domestic and international third-party tests, as well as other green, low-carbon and environmentally friendly tests and certifications.

ZD Vegetable Insulating Oil Product Parameters

Item		VS100	DL/T 1811-2018	IEC 62770
Physical Properties
Appearance		Clear and transparent	Clear and transparent	Clear and transparent
Kinematic Viscosity mm²/S	40℃	32.44	≤50	≤50
Kinematic Viscosity mm²/S	100℃	8.46	≤15	≤15
Pour Point ℃		-18	≤-10	≤-10
Water Content mg/kg		≤50mg/kg	≤200	≤200
Density kg/m³, 20℃		0.92	≤1	≤1
Electrical Properties
Breakdown Voltage kV		≥70kV, 2.5mm	≥35, 2.5mm	≥35, 2.5mm
Dielectric Dissipation Factor		0.012, 90℃	≤0.04， 90℃	≤0.05， 90℃
Relative Permittivity		3	-	-
Chemical Properties
Fire Point ℃		＞350℃	＞300	＞300
Flash Point ℃ (Open Cup)		＞320℃	＞250	＞250
Acid Value mgKOH/g		0.05	≤0.06	≤0.06
Corrosive Sulfur		None	None	None
Dibenzyl Disulfide (DBDS)		Not detected	Not contained	Not contained
PCB Content		Not detected	Not contained	Not contained
