Equipment Features:
Utilizes a unique magnetic matrix to precisely capture magnetic particles, ensuring complete removal of magnetic minerals;
Magnetic field intensity is continuously adjustable, up to 1.8T;
Adopts PLC fully automatic control, with the magnetic matrix requiring no disassembly for cleaning;
Employs forward and reverse high-pressure water and pulsed high-pressure air for ore discharge, preventing long-term blockage of the magnetic matrix;
Application Scope:
Suitable for iron removal and purification of non-metallic ores such as potassium-sodium feldspar, quartz sand, kaolin, nepheline, fluorite, kyanite, and sillimanite, as well as for the separation of fine-grained metallic minerals. It is particularly effective for purifying fine-grained non-metallic ores. When used in combination with the SLon vertical ring pulsating high-gradient magnetic separator, it can produce high-quality non-metallic concentrates.
