General Specifications

Specifications

Chipset

● 5G/LTE: UNISOC IVY510, dual-core ARM Cortex-A55 processor, up to 1.35GHz

● Wi-Fi chip: MT7621A

RF standard

● 5G NR(3GPP Release 15), FDD-LTE

Memory

● 5G module: Nand flash 2Gbits + RAM 4Gbits LPDDR4x

● Router: ROM 128Mbits + RAM 1Gbits

Button

● Power on/off button

● WPS button

● Reset key

Interface

● GE LAN Port*4

● SIM card slot * 1(3FF)

● DC socket

● TYPE_C USB3.1 for Manufacture

LAN/WAN

● GE Port*4, (Currently DHCP/STATIC mode)

Power

● AC power supply 100V ~ 240V, 50Hz ~ 60Hz

● DC power supply 12V DC ± 10% 2A

Power consumption

●<24W

Dimensions

● 117mm * 117mm * 180mm

Weight

● 580g

Output

power@25℃

● 5G:n41/77/78/79:Power Class 2

n1/20/28:Power Class 3

● LTE:Power Class 3

Power Class 2(only B41)

● WCDMA:Power Class 3

5G/4G antenna

● 4*5G built-in antenna

● 2*4G built-in antenna

5G/4G gain antenna

● 2 +/-2dBi

Wi-Fi FREQUENCY

● 2.4GHz/5GHz

Wi-Fi antenna

● 2*2.4G built-in Wi-Fi antenna

● 2*5G built-in Wi-Fi antenna

Wi-Fi output power

● 16dBm/2.4G;18dBm/5G;

Wi-Fi channel BW

● 20MHz,40MHz,80MHz(ac)

Wi-Fi gain antenna

● 4dB

Peak throughput

● NR:1.6Gbps(DL)/230Mbps(UL)

● LTE:600Mbps(DL)/150Mbps(UL)

● DC-HSPA+:42Mbps(DL)/5.76Mbps(UL)

● HSPA+:21Mbps(DL)/5.76Mbps(UL)

ENVIRONMENTAL SPECIFICATIONS

Ability

Working temperature

● 0 ℃ ~ 40 ℃

Storage temperature

●-20 ℃ ~ 70 ℃

Working humidity

● 95% Marston condensation

Storage humidity

● 95% Marston condensation

Wireless Internet function

● Support on/off Wi-Fi switch

● Support Wi-Fi bandwidth settings

● Support Wi-FiSSID/KEY setting

● Support Wi-Fi channel adaptation and selection

● Support encryption: OPEN,WPA2-PSK,WPA/WPA2-PSK,

● Support Wi-Fi up to 2.4G Wi-Fi:645G Wi-Fi:64

● Support SSID broadcast

● Support WPS: Support WPS PBC

● Support Wi-Fi protocol IEEE802.11b/g/n,IEEE802.11ac
