Product Introduction
The N-series hydrocyclone features a large cone angle design. A larger cone angle generates a higher rate of centrifugal force change, allowing fine particles to rapidly enter the inner vortex flow. Meanwhile, the higher slurry concentration at the cone section prevents fine particles from spilling into the outer vortex flow caused by localized recirculation.
Technical Features:
(1) Utilizes forced classification technology;
(2) Fluid dynamics simulation optimizes the cylindrical section ratio, extending classification time while maintaining low energy consumption;
(3) Customized cone angle design based on the user's material properties, reasonably improving overflow ratio and classification efficiency.
Application Scope:
Suitable for classifying materials with abnormal particle size distribution ratios (with a relatively large overflow fraction), as well as sand selection operations in construction sand processing.
Specifications and Models:
Shangpin Technology offers hydrocyclones in sizes ranging from Φ10-840mm, capable of classifying materials from 2-350μm.
Equipment Materials:
Shangpin Technology provides the Smax-PU series (pure nano-modified polyurethane), Smax-GT series (steel shell lined with high-alumina ceramic), Smax-GX series (steel shell lined with imported rubber), Smax-GJ series (steel shell lined with nano-modified polyurethane), and Smax-GK series (steel shell lined with wear-resistant composite ceramic).
