Classification: Biomass fuel, biomass power generation, biomass thermal power

Supporting power generation: 6-150MW

Exhaust gas temperature: <150°C
Rated steam pressure: 1.3 - 17.8MPa

Boiler guaranteed thermal efficiency: 86 - 92%
Rated steam temperature: 400 - 571℃

NOx original emission: <200mg/Nm³
Feedwater temperature: 105-270°C

SOz original emission: <300mg/Nm³
Design fuel calorific value: >8000KJ/kg

Design fuel: biomass, solid waste, etc.

Design bed temperature: 785-840°C

Ignition and stable combustion: natural gas, oil, etc.

Latest scientific and technological achievements

Taiguo--Tsinghua research team has gone through years of arduous engineering practice and exploration, and launched: the latest scientific and technological achievements of the one-stop solution of "new generation biomass circulating fluidized bed boiler thermal power system" that integrates the main boiler, auxiliary machine, environmental protection, and control!

Performance advantages of biomass products

◆Long cycle, high energy efficiency, stable environmental protection, and intelligent

◆Long cycle--integrated design of feeding system, low failure rate

Special hood air distribution has no dead zone, and iron parts are smoothly discharged

System reconstruction, stable cycle, no alkali corrosion and wear

Arrange evaporation tube bundle to ensure steam temperature

◆High energy efficiency--uniform feeding, good gas-solid mixing, high combustion efficiency

Feeding system has small air leakage and thermal efficiency High efficiency, low power consumption

◆Stable and environmentally friendly--uniform feeding, small oxygen fluctuation, easy control of NOx and SO2

High separation efficiency, excellent bed quality, balanced combustion, low original emissions, strong self-desulfurization ability, low SOz emissions

◆Intelligent--Promote biomass boilers to achieve high energy efficiency and stable environmental protection

Focus on solving: the overall ability of the operating team, the energy and sustainability of the operators

Biomass product engineering test

Heilongjiang Qingxiang Thermal Power's 80MW extraction condensing generator set 2600h high temperature and ultra-high pressure reheat boiler is currently the largest capacity and highest parameter pure herbal biomass product in China. It was successfully put into operation in July 2021. It has stable and reliable operation, and excellent energy efficiency and environmental protection indicators.

Zhongxin Thermal Power's 130uh high temperature and ultra-high pressure reheat boiler has a long operating cycle, high energy efficiency, and stable environmental protection indicators.
