Product Overview:
Horizontal split-casing structure with inlet and outlet both located on the pump body, supported by feet for easy inspection and maintenance.
Composed of two back-to-back single-suction impellers, some with adjacent blades staggered to reduce flow pulsation to ±1%~±2% of the head, ensuring smoother operation, more balanced flow, high head, large flow rate, and excellent cavitation performance.
Compact axial structure, small bearing span, high shaft rigidity, and stable pump operation.
Theoretically zero axial force, with a double-volute structure minimizing radial force and staggered adjacent blade arrangement.
Low pulsation, high reliability, and stable operation.
Designed with reference to excellent hydraulic models, incorporating advanced foreign technology, in collaboration with renowned domestic universities, and utilizing multi-condition parallel design for reliable performance, high efficiency, energy saving, stable operation, low noise, and low vibration.
Shaft seals available in packing seal or mechanical seal structures.
Technical Parameters:
Q: 65~25000m³/h
H: 10~270m
t: 0℃~80℃
Widely used in: water supply for waterworks, air conditioning circulation water, irrigation, drainage pump stations, power plants, industrial water supply systems, fire protection systems, shipbuilding industry, and other liquid transfer applications.
