Dump Truck
Multi-function, non-directional tread design for optimum usage on articulated equipment
Superior OTR performance in multiple types of terrain
Unique center block tread design provides additional traction, even wear and promotes retreadability
OEM Certified
| TIRE SIZE | PATENT | LOAD SYMBOL | SPEED (km/h) | OD (mm) | SW (mm) | TD (mm) | RIM | SINGLE TIRE LOAD (kg) | SINGLE TIRE PRESSURE (kPa) | LOAD INDEX | NOTE |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 14.00R25 | REM10 | ★★★ | 50 10 |
1356 | 375 | 25 | 10.00/2.0 | 5800 10000 |
700 950 |
169 188 |
E3 |
| 16.00R25 | REM10 | ★★★ | 50 10 |
1482 | 430 | 26 | 11.25/2.0 | 8000 13200 |
800 900 |
180 198 |
E3 |
| 16.00R29 | REM10 | ★★★ | 10 | 1625 | 452 | 33 | 11.50/2.5 | 14050 | 950 | 200 | E3 |
| 17.00R29 | REM10+ | ★★★ | 10 | 1625 | 452 | 33 | 11.50/2.5 | 14050 | 950 | 200 | E3 |
| 26.5R25 | REM10 | ★★ | 50 10 |
1754 | 695 | 40.5 | 22.00/3.0 | 11500 18500 |
450 575 |
193 209 |
E3/L3 |
| 29.5R25 | REM10 | ★★ | 50 10 |
1868 | 748 | 44 | 25.00/3.5 | 14000 22400 |
450 575 |
200 216 |
E3/L3 |
| 505/95R29 | REM10 | ★★ | 50 10 |
1705 | 515 | 32 | 13.00/2.5 | 10900 16700 |
800 1200 |
191 205 |
E3 |
| 480/95R29 | REM10 PRO | ★★★ | 10 | 1625 | 472 | 33 | 13.00/2.5 | 14050 | 950 | 200 | E3 |
