Product Series
| FLC10008 | Model | ||||
| “FLC” | FG-AMB Blower Brand | ||||
| “100” | Rated power: 100hp (75kW) | ||||
| “08” | Rated pressure: 80kPa | ||||
| Model | Specification | ||||
| Flow /(m³/min) | Pressure /(kPa) | Motor power/[hp(kW)] | Cooling | ||
| FLC050 Series | 18~53 | 20~120 | 50(37) | Air | |
| FLC075 Series | 15~70 | 20~120 | 75(56) | Air | |
| FLC100 Series | 22~70 | 20~120 | 100(75) | Air | |
| FLC150 Series | 45~135 | 20~120 | 150(110) | Air | |
| FLC200 Series | 50~140 | 20~120 | 200(150) | Air | |
| FLC250 Series | 60~170 | 20~120 | 250(188) | Air | |
| FLC300 Series | 70~200 | 20~120 | 300(220) | Air | |
| FLC400 Series | 100~260 | 20~120 | 400(300) | Air | |
*The above table is a brief introduction of each series of blower, For the specific project selection, please contact the salesperson.
Product Advantages
Technology
●The active magnetic bearing system is adopted without abrasion and no need of lubrication system.
●High-performance frequency converter is adopted to control the revolving speed and multiple control modes are available for choice.
●The advanced control system is adopted to monitor the operating status and is able to conduct remote control and there is no need to designate personnel for guarding.
●Fully enclosed air cooling are employed for heat dissipation of motor so as to guarantee the air blower stays at a stable and highly efficient operating status.
●The modular design makes the maintenance convenient and fast
Energy-saving
●In comparison to roots blower, the efficiency of maglev turbo blower is improved by 15~40%.
●Take the 150hp maglev turbo blower as the example. Compared with roots blower, each set can save more than 300,000kW/h electricity per year.
Environment protection
●With calculation of the 150hp maglev turbo blower, each set can reduce about 275 ton of carbon dioxide emissions per year.
●The maglev turbo blower requires no lubrication and the air it transmitted are clean and no pollution.
●The maglev turbo blower generate low noise and no impact the surrounding office and living environment.
Low operating cost
●The magnetic bearing is completely free of friction so that the possibility of product damage can be reduced and the service life of blower can exceed 20 years.
●The maintenance of maglev blower is easy and only replacement of filter is required.
●Maglev turbo blower requires no lubrication system, save the cost for lubricant.
●Compact design, save space.
●Low maintenance cost, timely after-sale service.
