Epoxy Cast Dry-Type Transformer for Marine Use

EXW
$22,154.94-221,549.37 /Unit
China
No.50 Courtyard, Rongxing North 3rd Street, Beijing Economic-Technological Development Area, Daxing District, Beijing
+86-13930247625
+86-13930247625
Online Contact
Favorite
Product Introduction

Providing stable and reliable power guarantee for mainstream commercial ships and high-end marine applications, supporting the safe operation of ship propulsion systems, and ensuring efficient and safe navigation.

Product Highlights:

  • Excellent Marine Environment Adaptability
    Adopts high protection level design, effectively resisting salt spray, damp heat, and seawater intrusion, meeting the requirements for long-term operation in harsh marine environments.
  • Efficient Thermal Management Capability
    Supports air-cooled/water-cooled heat dissipation solutions, achieving precise temperature control under high-load conditions, avoiding excessive temperature rise, and improving equipment reliability.
  • Convenient Operation and Maintenance Design
    Modular structure adapts to limited installation space on ships, simplifies maintenance processes, and reduces full-lifecycle operation and maintenance costs.
  • International Classification Society Certification Guarantee
    Meets the certification requirements of major international classification societies such as CCS, DNV, LR, BV, and ABS, ensuring the product complies with global ship application standards.
Product Parameters

Capacity

500~7000kVA

Primary Rated Voltage

0.38kV~13.8kV

Secondary Rated Voltage

0.38kV~13.8kV

Rated Frequency

50Hz/60Hz

Cooling Method

ANAF/AFWF/AF

Temperature Rise

F (max. 155℃)/H (max. 180℃)

Efficiency

≥98.5%

Ambient Temperature

0℃ ~+ 45℃

Communication Interface

RS485
