A pad-mounted compact substation in the American layout, built around an oil-immersed transformer with the MV load-break switch and fuse protection immersed directly inside the transformer tank. A double-tank horizontal arrangement keeps HV and transformer sections independently maintainable. Fully sealed and insulated (no clearance required), occupying only ~1/3–1/5 of the footprint of an equivalent European box substation — ideal for residential areas, malls, airports, railways and renewable sites.
1/1
American-Type Substation (ZGS Pad-Mounted)
EXW
$17,707.00-22,821.00 /Set
China
No. 388 Quanshun Road, Xiaolan Economic and Technological Development Zone, Nanchang County, Nanchang City, Jiangxi Province
18379983771
+86 13060075509
597108072@qq.com
Product Introduction
Technical Parameters
Key Specifications
High-voltage Rated Voltage 10 – 35 kV
Low-voltage Rated Voltage 0.4 / 0.69 / 0.8 kV
Maximum Operating Voltage 40.5 kV
Rated Frequency 50 / 60 Hz
Rated Capacity ≤ 3300 kVA
