Condensate pumps, Air conditioning technology EE 1650 M

Technical Data Pump unit (L x W x H): 244 x174 x144 mm Electrical spec.: 230V. 50/60Hz, 40VA Alarm switch: 230V, 8A (ohmic load) NO/NC (normally open/ normally closed) max. flow rate: 32 l/h max. delivery height: 15 m Tan......Technical Data Pump unit (L x W x H): 244 x174 x144 mm Electrical spec.: 230V. 50/60Hz, 40VA Alarm switch: 230V, 8A (ohmic load) NO/NC (normally open/ normally closed) max. flow rate: 32 l/h max. delivery height: 15 m Tank capacity: 2 l Start: 40 ± 2mm Stop: 30 ± 2mm Alarm: 52 ± 2mm Dimensions specified from the mounting surface Usage This compact unit with integrated float switch is designed to be used inside devices equipped only with a condensate collecting tank such as fan convectors, cabinet models, built-in units, water collection consoles… Steps must be taken to ensure that no fluid runs over the pump! Description The delivery system is equipped with 2 separately operating float switches. The working float switch turns the pump on and off depending on the filling level (with run-on time). The function of the alarm float switch is to isolate the break contact element.
