standard // options - longitudinal axis: 4.000 mm // 30.000 each 1.000 mm - transversal axis: 3.600 mm - clearance between columns: 4.000 mm - vertical axis: 1.500 mm // 1.750 mm - rotary head holder plate 180 index 2,5 /......standard // options - longitudinal axis: 4.000 mm // 30.000 each 1.000 mm - transversal axis: 3.600 mm - clearance between columns: 4.000 mm - vertical axis: 1.500 mm // 1.750 mm - rotary head holder plate 180 index 2,5 // 1 - 0,5 - 0,01 - axis 90 - tool changer: 20 places // 30 - 40 - 60 - 100 places - cnc: heidenhain // selca - fanuc - fidia - faceplate plane width: 2.500 mm - faceplate plane length: 4.000 mm // 30.000 each 1.000 mm - faceplate plane capacity: 100.000 n/m // 150.000 n/m - spindle: 407 mas - bt 50 - kw - s1: 30 - rpm: 4.800 // 6.000 - 12.000 - 16.000 - spindle axis inclination - index: horizontal / vertical // 2,5 - 1 - 0,5 - 0,01 - axis 35 - tool diameter: 125 mm - tool length: 350 mm - tool weight: 15 kg // 20 kg - linear axes speed: 20.000 mm/min - polar axes speed: 4.000 min - linear axes accuracy: 15+3 (l-1.000)/1.000 micron - polar axes accuracy: 8" where to buy this product contact the manufacturer
