double disc face grinding machine

diskus double surface lateral grinding machine with vertical spindle. this machine model is a steel-welded, box-frame design with greater rigidity than a comparable portal machine. the two vertical , directly driven motor......diskus double surface lateral grinding machine with vertical spindle. this machine model is a steel-welded, box-frame design with greater rigidity than a comparable portal machine. the two vertical , directly driven motor spindles with liquid cooling each have an output of 23 kw to 48 kw. they are attached to rolling bearing compact carriages which perform all feed and return motions with a precision screw drive. the machine version required for this application can be used as a plunge cut as well as throughfeed grinding machine. a number of parts can be ground simultaneously with the planetary drive provided with controlled rotation. while they are fed to the grinding tools using the plunge cut process in a planetary gear which rotates around its own axis. replacement of the transport plate allows the same machine to be used for throughfeed grinding.
