Hardware capability information

Project

Content

Main chip

Amlogic S905X4

FLASH

8GBEMMC

RAM

2GB DDR4

OS

AndroidTM12

DRM

WV L1

Product features

Module

Content

Regular characteristics

Ultra-low power consumption

4Kp60 AV1,4Kp6010-bit H.265;4Kp60

VP9 Profile2 decoding

Over-the-air remote: support Android and IOS phone control

System upgrade: Software upgrade via USB or network

Android features

Built-in Netflix,Amazon Prime Video,Youtube

Audio and video decoding

Video Decoding: HD AVC/MPEG-2/VC-1;H.265/HEVC UHD4K p60;H.264/AVC

main and high profile, 1080P 60fps; VC-1simple, main, and advanced profile @level 3; 10bit VP9; MPEG4 Part2, DivX 3.11, 4.x, 5.x; HD MPEG-2 and SDMPEG-2; MPEG still-picture decode; HDRHLG, HDR10;

Audio decoding: AAC-LC and HE AACV1/N2decoding; Dolby®Digital, Dolby Digital Plus; MPEG I layers 1,2;MP3; Windows Media@audio;

3D Graphics: OpenGLES 1.1/2.0; OpenVG 1.1

Dolby: Dolby Video: Dolby Atmos (DD + included); Dolby Audio: Dolby Vision

Network

RJ45 interface, 10M/100M adaptive

2×2 MIMO Wi-Fi 2.4GHz/5.8GHz 802.11

a/B/g/n/ac, can support WIFI6 module, 802.11

a/ B /g/n/ac/ax

Bluetooth 5.0

External interface information

Project

Content

HDMI interface

1 * HDMI2.1 interface

AV interface

1*3.5mm caliber four-segment conversion interface, CVBS output + left and right channels

Audio interface

1 * SPDIF interface

Ethernet port

● 1*10/100Mbit/s adaptive RJ-45 interface

USB interface

● 1 * USB2.0;1 * USB3.0

TF card interface

● 1 * TF card interface

Power Interface

1 * outer diameter 5.5mm, inner diameter 2.1mm, inner positive and outer negative 12V DC power interface

Key

● 1 * Reset button

Accessories information

Accessory name

Specification requirements

Remarks

Power adapter

DC 12V/1A line length not less than 1.5m

Standard

HDMI cable

HDMI2.0 line length is not less than 1.5m

Standard

Remote control

Bluetooth remote control

Standard

RF line

Black, 1.8 m

Optional

Network cable

Wire length not less than 1.5m, two male plugs, category 5 twisted pair

Optional

AV Line

The wire length is not less than 1.5m and one end is 3.5mm earphone plug.

Optional
