1 kV~35 kV Cross-linked Polyethylene Insulated Power Cable

Negotiable
China
No.2800 Guanghua Road, Minhang District, Shanghai
13918556500
Online Contact
Favorite

Product Introduction

Product Features Feature

This product is the mainstream cable with the widest application and the best cost-performance ratio in current power distribution systems. It offers excellent electrical performance, with insulation made of cross-linked polyethylene featuring a high voltage withstand level; it has a high temperature rating, with a long-term allowable operating temperature of up to 90°C and a large current-carrying capacity; it exhibits good mechanical and physical properties and a long service life; it is easy to install and has a wide range of applications. In addition, the halogen-free, low-smoke, flame-retardant type of this product does not propagate flame after ignition, and possesses characteristics such as being halogen-free, low-smoke, non-toxic, and non-corrosive.

Product Parameters

Working Conditions Working condition

1. Maximum conductor operating temperature: 90°C.

2. Under short-circuit conditions (with a maximum duration not exceeding 5s), the maximum conductor temperature shall not exceed 250°C.

3. Installation ambient temperature: 0°C.

4. Allowable bending radius of the cable: not less than 20 times the outer diameter for single-core cables, and not less than 15 times the outer diameter for three-core cables.
