CBGNL Tandem Gear Oil Pump
High-strength cast iron housing for high load capacity
Patented structural design with self-lubricating bearings increases working pressure and maintains high volumetric efficiency
Input shaft connection options: parallel key, rectangular spline, involute spline, SAE spline
Inlet and outlet port connections available in flange, thread, and other options
| Model |
Nominal Displacement (mL/r) |
Pressure (MPa) |
Speed (r/min) |
Volumetric Efficiency (≥%) |
|||
| Rated | Max. | Min. | Rated | Max. | |||
| CBGNL-F63/F20-BF** | 63/20 | 25 |
28 | 800 |
1500 |
2000 |
90/90 |
| CBGNL-F63/F10-BF** | 63/10 | ||||||
| CBGNL-F50/F25-BF** | 50/25 | ||||||
| CBGNL-F50/F20-BF** | 50/20 | ||||||
| CBGNL-F50/F16-BF** | 50/16 | ||||||
| CBGNL-F50/F10-BF** | 50/10 | ||||||
| CBGNL-F46/F10-BF** | 46/10 | ||||||
| CBGNL-F40/F25-BF** | 40/25 | ||||||
| CBGNL-F40/F20-BF** | 40/20 | ||||||
| CBGNL-F40/F16-BF** | 40/16 | ||||||
| CBGNL-F32/F20-BF** | 32/20 | ||||||
| CBGNL-F32/F16-BF** | 32/16 | ||||||
| CBGNL-F32/F10-BF** | 32/10 | ||||||
