- Product Description
Internal stable-flow valve: the oil inlet section with an internal stable-flow valve to provide stable flow for steering system.
Internal check valve: each valve section has an internal check valve to prevent the oil backflow.
Double oil inlet ports: it is used for combining the flow of 2 pumps, to meet the hydraulic system with large flow.
The flow of two pumps can be combined to meet the needs of the large flow hydraulic system.
Self-lock of valve shaft: prevent vibration of forklift door frame caused by the negative pressure of tilt cylinder, and when the engine stalls it will lock the tilt cylinder to avoid the malfunction which is possible to result in a safety hazard.
Double relief valves: the main relief valve control the pressure of whole hydraulic system, the dividing relief valve ensures the normal working pressure of steering system.
Auxiliary valve: according to the requirement, overload valve and oil filling valve can be added at both ends of valve section.
Structure type: sectional valve, any 1 to 8 sections may combine upon customer's requirement.
Spool function at neutral position: A, Z, O, Y, etc.
