cnc turning center

cnc automatic lathe sc-20 - low price and satisfactory standard specifications. - low production cost due to reduction of materials. - headstock and tool post configuration of high rigidity and high precision. specificati......cnc automatic lathe sc-20 - low price and satisfactory standard specifications. - low production cost due to reduction of materials. - headstock and tool post configuration of high rigidity and high precision. specifications max. machining diameter 20mm(25/32in) max. headstock stroke bar diameter2.5(max.55mm) 4-spindle sleeve holder (for front working side) - max. drilling capacity 10mm(25/64in) - max. tapping capacity m8p1.25 power-driven attachment - max. drilling capacity 6mm(15/64in) - max. tapping capacity m5p0.8 main spindle speed max.10,000min-1 main spindle motor 2.2kw/3.7kw power-driven att. spindle speed max.5,000min-1 power-driven att.drive motor 0.4kw dimension(wdh) 1,8551,0601,750mm weight 1,600kg
