Model FS 384

Characteristics of the flat grinding model FS 384 Workpiece dimension: width 150 mm x height 100 mm and any length Special versions for parts with height 150 mm Special conveyors for parts which are not flat like door pla......Characteristics of the flat grinding model FS 384 Workpiece dimension: width 150 mm x height 100 mm and any length Special versions for parts with height 150 mm Special conveyors for parts which are not flat like door plates Belt grinding main drive 5,5 kW / 7,5 HP or 7,5 kW / 10 HP Pressure controlled grinding head for constant stock removal Belt tension by adjustable pneumatic cylinder Belt dimension 150 mm wide by 2500 mm length Workpiece transport by frequency driven belt conveyor Infeed and Outfeed by roller guide Optional handling system with return conveyor for automated operation Buffing stations with angle adjustment Buffing pressure controlled with wear compensation Wax system with solid or liquid compound feeder Applications: Surface improvement and conditioning for: plating, descaling, decorative grinding, finishing, linishing, degreasing, cleaning, calibrating, deburring, satin finishing, brushing, polishing, mirror finishing, superfinishing, microfinishing, removing defects, edge rounding, leveling, decor finish, precision cutting, slag grinding Workpiece and parts: Strip, tubes, squares and profiles for furniture industry, decorative stainless, shop interior, engine components, sinter parts, punched, laser cutting, sheet metal, stamping, discus ground parts, sinter metal, textile parts, ceramic parts, Configuration: The belt grinding machines can be equipped with 2 or 4 or 6 stations in one cabinet. Multihead machines with 8, 10, 12 heads are configured with 4+4 or 6+2 cabinet combinations. The system is fully modular and easy to upgrade with additional stations to grow with future needs of our customers. Enclosed versions with noise, water and dust proof cabinets maximize operating comfort and easily comply with highest safety standards. Dry versions and low cost open design versions are available also. Manual up to fully automatic adjusting systems to customer’s product sizes minimize the setup time loss and maximize the production and profit. Fist class components - all spindles, screws and bolts are stainless steel. This guarantees maximum life time of products. Optional features like complete belt station in stainless, drying stations, camera part detection, surface checking, wear compensation and more is available. FS384 light duty 6 Station Belt grinding line These enclosed versions are available in 4 and 6 stations in a single cabin. 8 station systems are build with two 4 station cabins. The noise reduction cabin is used for wet grinding mainly but also dry applications suit. In dry operation dust remains in the cabin and is filtered by air filter systems. The compact design reduces floor space and enables for quick installation. The workpiece return conveyor is in the machine for safety reasons. The shown flat belt grinding solution is equipped with automatic tube manipulators to load to the return conveyor. Belt guards are on all Loeser flat grinding systems with stainless steel belt guards.
