Presenting the new Hwacheon M2 3 AX machining centre

Super large production VMC with a frame bridge structure. High Speed & Precision Multifunction machining center for prismatic parts and combinging operations into one set up. Item Unit Specifications Unit Specifications T......Super large production VMC with a frame bridge structure. High Speed & Precision Multifunction machining center for prismatic parts and combinging operations into one set up. Item Unit Specifications Unit Specifications Table Size mm 1,100x650 inch 43.3x25.6 Max. weight on Table KG 1,500 lbs 3,307 X/Y/Z Axis mm 950x650x 500 inch 37.4x25.6x19.7 Rapid Traverse (X/Y/Z) m/min 50 / 50 / 50 ipm 1970 / 1970 / 1970 Spindle Motor kW 22/18.5 hp 30 / 25 Spindle Speed RPM 20,000 (30,000 / 40,000) RPM 20,000 (30,000 / 40,000) Spindle taper hole NT NT No.40 NT NT No.40 Machine weight KG 10,500 LBS 23,150 Floor space(LW) mm 2,550)x3,665 inch 100.4x144.3 Electric Power More information...
