horizontal spindle surface grinding machine with rotating table

due to its versatility and simplicity of use it represents the state of art in surface grinding technology. the machine can be programmed to work in manless operation manner. it is equipped with the rosa system n unit, bu......due to its versatility and simplicity of use it represents the state of art in surface grinding technology. the machine can be programmed to work in manless operation manner. it is equipped with the rosa system n unit, but it is also available in the nc version system vi (siemens sinumerik 840 di). six models are available whose rotary table diameter of d=400, 600, 800, 1000, 1200, 1500 mm. the wheel spindle is of the interchangeable cartridge type and runs on opposed preloaded angular precision bearings. the standard power-rate of the wheel motor is 11 kw (15 kw for rotor 1200 and 1500).
