Valve body structure
· The valve body of the T-type three-way ball valve is at a 90° angle to the pipeline

The valve body of the L-type three-way ball valve is at a 90° angle to the pipeline

The standard design of the Y-type three-way ball valve is 120° and 135°, and the design angle can be customized according to the requirements of the on-site piping

2 Four-seat design
The ball is more balanced in force

Avoid shear and bite damage to the valve stem due to unbalanced force

Prevent cross contamination when conveying different materials
3 Functional characteristics
· Realize the diversion, confluence and mixing of the medium ·

Possess all the characteristics and advantages of floating ball valves

- Technical parameters

Size range NPS 1/2-NPS 24 (DN 15-DN 600)
Pressure level ASME CLASS 150~900PN 10-PN 150
Temperature range -196°C to +260°C

For specifications and models of TT, TL and TY series three-way fixed ball valves, please contact SUC Technical Department

- Design standards and specifications

Design standards ASME B16.34, API 6D API 608, BS 5351 GB/T 12237
Structural length standards ASME B16.10, GB/T 12221
Flange standards ASME, HG/T, GB/T, JB/TSH, DIN, JIS
Fire test API 6FA, API607
Test standards API 598, 1S0 5208GB/T 13927, JB/T 9092
Low fugitive emission test I50 15848-1, TA-LUFT

- Application industries

Oil and gas
· Petrochemical

· Chemical industry

· Silicone

· Polysilicon
· Metallurgy
· Mining
· Electricity

· Coal chemical industry

- Application areas

Liquid transportation

Gas transportation

Powder transportation
Gas-liquid and powder three-phase flow transportation
