E308L-16
AWS A5.4 E308L-16
ISO3581-A-E19 9 L R
GB/T 983 E308L-16
Description：
A rutile type stainless steel electrode with extra low C content (≤0.04%) designed to weld stainless steels with working temperature under 300℃, such as SUS304, etc. Excellent operation Properties (All Weld Metal) and pores resistance, great mechanical and intercrystalline corrosion resistance performance.
Diameters:
1.6mm, 2.0mm, 2.5mm, 3.2mm, 4.0mm, 5.0mm.
Typical Mechanical Properties (All Weld Metal):
|
Tensile strength(MPa): |
610 |
|
Yield strength(MPa): |
-- |
|
Elongation(%): |
41 |
Typical Chemical Composition (Wt.%, All Weld Metal):
|
C |
Mn |
P |
S |
Si |
Ni |
Cr |
Mo |
Cu |
|
0.021 |
0.72 |
0.02 |
0.005 |
0.62 |
9.75 |
19.22 |
0.13 |
0.25 |
Welding Current:(AC/DC＋)
|
Diameter(mm) |
2.5 |
3.2 |
4.0 |
5.0 |
|
|
Current/A |
F/H |
60-80 |
80-120 |
100-150 |
140-180 |
|
Current/A |
V/OH |
40-70 |
60-100 |
80-130 |
-- |
