Technical Parameters:
Maximum Head: 35 meters
Maximum Flow: 40m³/hour
Total Power: 0.75KW-15KW
Pump is "Liancheng" cutting sewage pump, protection rating IPX8, submersible motor
Nominal Pump Station Capacity: 250-1800L (250L/400L/700L/1000L)
The cutting-type sewage pump with a blade head is installed in the container with a default auto-coupling system (other installation methods optional, subject to negotiation), making replacement and maintenance more convenient.
Product Features:
Non-clogging: Equipped with a unique cutting blade head, long fibers are cut before entering the pump, preventing entanglement and clogging. Particularly suitable for media with long fibers or small particles, extending the pump's service life. The drainage pipe can use a smaller diameter without clogging, reducing the amount of earthwork in construction, saving space, and lowering costs.
Pollution-free: Fully enclosed design prevents sewage overflow, with a dedicated exhaust pipe to discharge internal gases to outdoor spaces, ensuring no odor and protecting the surrounding environment.
Remote Monitoring (Optional): Based on customer needs, the device can be equipped with a remote monitoring system, allowing operators to monitor equipment status intuitively without leaving their post. Equipped with internal liquid level float switches, combined with an automatic control box, enabling automatic start/stop of the unit and high liquid level alarms.
Space-saving: Built-in high-efficiency, energy-saving motor, compact design, high reliability, and small overall footprint. Flexible installation saves construction investment costs and reduces expenses.
