Type/Applications:
WYJZWG4: Meet with requirements of pollution class IV
Max. system voltage: 72.5kV, applicable to 120~1600mm²
Max. system voltage: 126kV, applicable to 240~1600mm²
Max. system voltage: 145kV, applicable to 240~1600mm²
Features:
- 1. Seamless manufacturing process greatly improves mechanical and electrical properties of termination surface.
- 2. Good weather resistant, anti-tracking, arc-erosion resistant, hydrophobic and pollution flashover prevention properties, which ensures safe and long-term operation even under severe and highly polluted environments.
- 3. One-piece outdoor termination, only 1/8~1/10 of the weight of porcelain type termination at equivalent voltage level, catering for more convenient installation.
- 4. Good anti-explosion property prevents casualty resulted from explosion.
- 5. Dry design, free of oil or gas leakage.
- 6. Flexible installation renders either inclined or inverted mounting.
- 7. Type tested according to IEC 60840, GB/T11017.
