The CLW5180TXSD6 washing and sweeping truck adopts the Dongfeng Tianjin DFH1180EX8 Class II chassis, equipped with a Cummins B6.2NS6B230 engine (169kW), a wheelbase of 5000mm, and a gross vehicle weight of 18000kg. The upper body is equipped with a 9m³ water tank and a 7m³ garbage bin. The auxiliary engine drives the fan, high-pressure water pump, and hydraulic system, enabling functions such as washing and sweeping, curb cleaning, rear spray dust suppression, low-pressure flushing, high-pressure cleaning, and self-cleaning. The sweeping efficiency is ≥95%, and the maximum sweeping width is approximately 3.5m.
| Vehicle Model | CLW5180TXSD6 |
|---|---|
| Product Name | Dongfeng Tianjin Washing and Sweeping Truck |
| Chassis Model | DFH1180EX8 |
| Actual Volume | Water tank rated capacity 9m³, garbage bin rated capacity 7m³ |
| Overall Length | 9350,8850,8550,8250,8050,7750,7500,7350 mm |
| Overall Width | 2480,2500 mm |
| Overall Height | 3130,3080,3100,3160 mm |
| Gross Vehicle Weight | 18000 kg |
| Curb Weight | 11000,12460,11800,12320 kg |
| Rated Payload | 6870 kg |
| Announced Wheelbase | 3800,3950,4200,4500,4700,5000,5300,5800,5600,5100 mm |
| Tires | 10.00R20 18PR,275/80R22.5 18PR,295/60R22.5 18PR |
| Axle Load | 6500/11500 kg |
| Approach Angle/Departure Angle | 17/12 ° |
| Front Track | 1876,1896,1920,1950,1914,1934,1980,2000,1815,1860 mm |
| Rear Track | 1820,1860,1800,1840 mm |
| Leaf Spring Count | 7/9+6,8/10+8,8/9+6,11/10+8,3/10+8,2/3+2,3/4+3,2/10+8 |
| Number of Axles | 2 units |
| Cab Approved Passenger Capacity | 2,3 persons |
| Maximum Speed | 89 km/h |
