The GSZB-6A double-cylinder double-liquid grouting pump is mainly used in tunnel excavation and maintenance, foundation engineering for roads, bridges, dams, mines, high-rise buildings, and various grouting operations. It primarily uses hydraulic pressure to inject cement slurry and mortar into cracks or cavities in rock or soil, thereby preventing leakage and settlement and strengthening foundations.
Product Advantages
-
Large grouting volume and high outlet pressure
Reasonable overall layout, small size, and light weight make it easy to move and transport, allowing operation in complex and narrow spaces
-
High cost-effectiveness and high efficiency
Equipped with a contactor and thermal relay to protect the motor, ensuring safety and reliability
Technical Parameters
| Name | Parameter |
| Production Capacity | 6m³ /h |
| Working Pressure | 11MPa |
| Overall Weight | 580KG |
| Dimensions | 1830× 800 1140mm |
| Maximum Delivery Distance | 300/100m (horizontal/vertical) |
| Main Motor Power | 15kW |
| Aggregate Diameter | 3-5mm |
| Grouting Pipe Inner Diameter | 32mm |
| Slurry Suction Pipe Inner Diameter | 51mm |
