HS TYPE MINICENTERS

The new HS minicentres proposed by BIEMMEPI SISTEMI define new standard in light millings and engraving operations, thank to their extremely innovative features. The dynamic performances of the new minicentres are really ......The new HS minicentres proposed by BIEMMEPI SISTEMI define new standard in light millings and engraving operations, thank to their extremely innovative features. The dynamic performances of the new minicentres are really the best available on the market for this kind of machines: Rapid traverse rate: up 50.000 mm/min. Axes acceleration: up to 10 m/s2 Tool change time: 2 sec. Axes resolution: 0.5 micron Spindle rotation: 36.000 rpm/min. The high performances of the HS minicentres are possible thanks to new brushless digital servomotors for all the axes, the new CNC Windows XP based and a stiff and sophisticated mechanical structure. The base of the machine contains all the service components, as vacuum pumps, cooling systems, air filters and also the electrical and electronic devices. The structure has been provided by chutes to collect the chips produced during machining in a sealed box. The covers of the machine are studied to protect the working environment from dust and noise and let the operator really free for maintenance or setup operations. The mechanical unit has very compact size to save space in the workshop. Thanks to their speed and the high resolution the minicentres HS are suited both for production and for small mould or EDM electrodes. Technical data regarding HS series engraving minicenters GS30 Cast iron gantry structure Spindle power rating: 1000 W (S6) - 570 w Slide-spindle nose distance: 200 mm Opening between uprights: 450 mm Automatic tool change with 9 places Maximum stem diameter for tools: 10 mm Tapping operations available Acceleration and Jerk settings depending on machining type CNC Windows XP based Smooth function in CNC for surfaces Dimensions (LxPxH): 900x1600x1800 mm Electricals 240 V single phase Air pressure: 6 bar Machining area: X=500 mm Y=300 mm Z=75 mm Weight: 430 kg
