Floor-Type Vertical-Spindle Machining Centers

Floor-Type Vertical-Spindle Machining Centers Item #: MC 302 GEOS - 5 5 axis (X, Y, Z, C, A) controlled by CNC. Suitable for working on 5-sides. The main axis slide on the slideways with ball recirculation and they are dr......Floor-Type Vertical-Spindle Machining Centers Item #: MC 302 GEOS - 5 5 axis (X, Y, Z, C, A) controlled by CNC. Suitable for working on 5-sides. The main axis slide on the slideways with ball recirculation and they are drive by brushless motors. The working table (X axis) can be divided in two areas so to get two separate working stations. The piece under working is locked pneumatically both in horizontal and in vertical. Profile holder system (no. 8) slides on precision slideway. Linear and circular interpolation on the axis X-Y-Z. The spindle head can be rotated (C) on any angle within ± 220º, and the spindle (A) can be positioned on any angle within ± 125º. The electric-spindle is suitable for quick tools change. The tool magazine is mounted on the mobile upright. The tool change can be carried out into any position belonging to the working area. The tools cooling is done through a centralized system that optimizes the required minimal lubrication. All slideways and ball recirculation screws are lubricated through an automatic centralized system. Designed in accordance with the EC rules.
