This product is a cross-linked polyolefin insulated wire and cable with a rated voltage of 450/750V and below, suitable for fixed wiring and electrical or electronic equipment that require heat resistance at temperatures of 105°C and above.

1. Product Overview:

• This is a cross-linked polyolefin insulated wire and cable with a rated voltage of 450/750V and below.

2. Application:

• Suitable for fixed wiring and electrical or electronic equipment that require heat resistance at temperatures of 105°C and above.

3. Features:

• Rated Voltage (U0/U): 450/750V, 300/500V.

• Permissible Long-Term Operating Temperature:

  • Temperature Grades: 105°C, 125°C, 150°C.

• Installation Temperature: The ambient temperature during cable installation should not be lower than 0°C.

• Bending Radius:

  • For cables without armor or with a flexible shielded structure: The bending radius should be no less than 6 times the outer diameter of the cable.
  • For cables with armor or copper tape shielding: The bending radius should be no less than 12 times the outer diameter of the cable.
