Overview
The detector can continuously monitor the indoor gas concentration. When the gas concentration exceeds the set standard, it sends out audible and visual alarm signals and simultaneously delivers the alarm data to the paired gas meter through wireless transmission, enabling the meter to cut off the gas source and transmit the alarm data to the IoT platform.
Technical Parameters
|
Specifications |
|
|
Frequency range |
901.3Mhz/ 477.3Mhz |
|
Transmit power |
5~20dBm |
|
Receiving sensitivity |
-139dBm@292bps |
|
Air transmission rate |
292bps~15.6kbps |
|
Supply voltage |
3.6V |
|
RF part emission current (typical value) |
90mA@20dBm |
|
RF part sleep current (typical value) |
3μA |
|
Bluetooth part transmit current |
14mA@0dBm |
|
Bluetooth part receives current |
13mA |
|
Bluetooth part sleep current |
5μA |
|
Antenna impedance |
50Ω |
|
Small size |
225mm×60mm×35mm |
