Single spindle bar automatic lathe TNK36

Within the short turning machine series, the TNK36 offers the largest processing diameter with a rod opening of 36 mm. Short chip-to-chip times of 0.55 sec. and motor spindles with a maximum of 10.7 kW ensure a high level......Within the short turning machine series, the TNK36 offers the largest processing diameter with a rod opening of 36 mm. Short chip-to-chip times of 0.55 sec. and motor spindles with a maximum of 10.7 kW ensure a high level of cost effectiveness.1 / 1High production rates due to simultaneous machining with up to 3 tool carriers at the main and counter spindle chip to chip time 0.55 sec. Backworking with tool drive for up to 5 tools Main and counter spindle with hollow shaft motors and synchronous drive technology Tool carrier, used as multifunctional turrets with high speed indexing and 12 stations (individually or centrally driven) Standard tooling and fast tool mounting as well as short set-up times Front attachment with 5 or 7 stations for fixed and driven tools Easily accessable work area from both sides The kinematics1 / 1 Modular system with up to three independent tool carriers The single spindle fixed headstock CNC automatic TNK36 is designed for the production of higher lot sizes from bar stock up to 36 mm DIA. Depending on part complexity, 3 to 6 linear axes are available and up to 3 tools can be simultaneously in cut on two spindles with a turning length of 100 mm. View into the work area1 / 5 Work area of the TNK36 The innovative feature is the design of main and counter spindle with synchronous drive technology. This new technology provides high drive power, torque and C-axis stiffness in a compact design package. The front attachment and the counter spindle are positioned precisely by a linear motor, also with synchronous drive technology. This drive accelerates extremely fast to a very high traverse rate of 60 m/min.
