Back-pressure Steam Turbine

Back-pressure Steam Turbine

Model

Power MW

Inlet parameters

Exhaust

Pressure MPa

Temperature ℃

Maximum steam volume t/h

Pressure MPa

B1.5 ~ B3

1.5~3

2.35~4.90

390~470

15~50

0.294~0.981

B6 ~ B9

6~9

2.35~8.83

390~535

60~180

0.294~3.92

B12 ~ B15

12~15

3.43~8.83

435~535

120~300

0.294~3.92

B18 to B20

18~20

3.43~8.83

435~535

150~350

0.294~3.92

B25 ~ B30

25~30

3.43~8.83

435~535

180~550

0.294~3.92
