Extraction Condensing Steam Turbine

Extraction Condensing Steam Turbine

Model

Power MW

Inlet parameters

Extraction parameters

Pressure MPa

Temperature ℃

Maximum steam volume t/h

Pressure MPa

Rated/max. t/h

C1.5 ~ C3

1.5~3

2.35~4.90

390~470

22~35

0.294~0.981

10~20/15~25

C6 ~ C9

6~9

2.35~4.90

390~470

42~80

0.294~1.27

15~45/20~55

C12 ~ C15

12~15

2.35~4.90

390~470

80~120

0.294~1.57

45~70/70~90

C12 ~ C15 (air cooling)

12~15

2.35~4.90

390~470

90~130

0.294~1.57

45~70/70~90

C18 ~ C20

18~20

3.43~8.83

435~535

100~140

0.294~1.57

50~70/70~90

C18 ~ C20 (air cooling)

18~20

3.43~8.83

435~535

105~150

0.294~1.57

50~70/70~90

C25 ~ C30

25~30

3.43~8.83

435~535

160~250

0.294~3.92

50~120/80~180

C25 ~ C30 (air cooling)

25~30

3.43~8.83

435~535

170~260

0.294~3.92

50~120/80~180

C50 ~ C60

50~60

4.90~8.83

470~535

300~350

0.294~3.92

100~170/160~240

C50 ~ C60 (air cooling)

50~60

4.90~8.83

470~535

310~360

0.294~3.92

100~170/160~240
