Driven - Extraction Condensing Steam Turbine

Extraction Condensing Steam Turbine

Model

Power kW

Steam intake t/h

Inlet parameters

Extraction pressure MPa

Steam extraction t/h

RPM

Pressure MPa

Temperature ℃

C3.85-3.43/0.70

3850

29.56

3.43

435

0.70

20

8600

C4.62-4.90/0.98

4620

38.50

4.90

470

0.98

30

7970

C5-3.43/0.98

5000

36.00

3.43

435

0.98

20

3000

C7.24-3.43/0.785

7240

49.28

3.43

435

0.785

25

10500

C8-3.53/0.70

8000

51.00

3.43

435

0.7

40

5800

C8.5-4.90/0.98

8500

62.80

4.90

470

0.98

40

6289

C25-3.43/0.687

25000

3.43

435

0.687

5362

C30-9.50/4.10

30000

129.10

9.50

435

4.1

13.5

5225

● Drive speed can be according to user requirements
