WGCB Series Aircraft Deicer

Negotiable
China
No.16, Huanghe Street, Huancui District, Weihai City, Shandong Province, China (264200)
+86 631 3803235
Online Contact
Favorite
Product Introduction

WGCB series Aircraft Deicers are designed to provide excellent solution required for mobile deicing and anti-icing for all types of civil aircraft except A380.

Safety

  • Emergency stop buttons;
  • Emergency hydraulic pump;
  • Anti-collision sensors and switches at the bottom of the basket;
  • Low fluid level protections;
  • Engine protections.

Features

  • Centrifugal deice pump;
  • Diaphragm anti-icing pump.

APPLICABLE

Applicable to all known civil aircraft types except A380.

Product Parameters
MAIN CONFIGURATION OPTIONAL
Chassis HOWO/SITRAK/MAN Enclosed Basket
Auxiliary Engine Cummins/Deutz Air Blowing System  360° Panorama Camera
    Proportional Mixing System  Telemetry
    Ticket Printer
PARAMETERS
  Instant Heating Preheating
  Model WGCB40E WGCB80E WGCB40P
Total Tank Capacity 6,000 L 8,000 L 6,000 L 8,000 L
Heat Up Time ≤ 3 mins ≤ 60 mins
Spray Pressure 1.0 MPa ~ 1.3 MPa (de-icing), 0.4 MPa~0.6 MPa (anti-icing)
Max. Flow Rate 227 L/min (de-icing), 90 L/min (anti-icing)
Basket Capacity 204 kg (open), 160 kg (enclosed)
Max. Speed While Deicing ≤ 5 km/h
Max. Drive Speed 60 km/h
Working Height 1,450 mm
Rotation ±175°
