Features and Benefits IPv6 Ready logo awarded (IPv6 Logo Committee certified) IEEE 1588 PTP (Precision Time Protocol) for precise time synchronization of networks DHCP Option 82 for IP address assignment with different po......Features and Benefits IPv6 Ready logo awarded (IPv6 Logo Committee certified) IEEE 1588 PTP (Precision Time Protocol) for precise time synchronization of networks DHCP Option 82 for IP address assignment with different policies Modbus/TCP industrial Ethernet protocol supported Turbo Ring and RSTP/STP (IEEE 802.1w/D) IGMP snooping and GMRP for filtering multicast traffic from industrial Ethernet protocols IEEE 802.1Q VLAN and GVRP protocols to ease network planning QoS (IEEE 802.1p/1Q) and TOS/DiffServ to increase determinism IEEE 802.3ad, LACP for optimum bandwidth utilization IEEE 802.1X, HTTPS, and SSH to enhance network security SNMPv1/v2c/v3 for different levels of network management RMON for efficient network monitoring and proactive capability Bandwidth management prevents unpredictable network status Lock port limits access to authorized MAC addresses only Port mirroring for online debugging Automatic warning by exception through email, relay output Automatic recovery of connected device s IP addresses Line-swap fast recovery Configurable by Web browser, Telnet/Serial console, Windows utility, and ABC-01 automatic backup configurator Introduction The PowerTrans PT-7728 is designed to meet the demands of power substation automation systems (IEC 61850-3, IEEE 1613), traffic control systems (NEMA TS2), and railway applications (EN50121-4). The PT-7728 s Gigabit and fast Ethernet backbone, redundant ring, and 24/48 VDC or 110/220 VDC/VAC dual isolated redundant power supplies increase the reliability of your communications and save on cabling/wiring costs. The modular design of the PT-7728 also makes network planning easy, and allows greater flexibility by letting you install up to 4 Gigabit ports and 24 fast Ethernet ports. Along with the optional front or rear wiring, these features together make the PT-7728 suitable for a variety of industrial applications. This product supports expansion modules. Click here for info on available modules. Technology: StandardsIEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) and 100Base FX IEEE 802.3ab for 1000BaseT(X) IEEE 802.3z for 1000BaseSX/LX/LHX/ZX IEEE 802.3x for Flow Control IEEE 802.1D for Spanning Tree Protocol IEEE 802.1w for Rapid STP IEEE 802.1Q for VLAN Tagging IEEE 802.1p for Class of Service IEEE 802.1X for Authentication IEEE 802.3ad for Port Trunk with LACP ProtocolsIGMPv1/v2 device, GMRP, GVRP, SNMPv1/v2c/v3, DHCP Server/Client, BootP, TFTP, SNTP, SMTP, RARP, RMON, HTTP, HTTPS, Telnet, SSH, Syslog (Available Soon: DHCP Option 66/67/82, LLDP, Modbus/TCP, IEEE 1588 PTP, IPv6) MIBMIB-II, Ethernet-like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9 Flow ControlIEEE 802.3x flow control, back pressure flow control ? Switch Properties: Priority Queues4 IGMP Groups256 Max. Number of Available VLANs64 VLAN ID RangeVID 1 to 4094 ? Interface: Fast EthernetSlots 1, 2, and 3 for any combination of 4, 6, 7, or 8-port PM-7200 fast Ethernet modules with 10/100BaseT(X) (TP/M12 interface), 100BaseFX (SC/ST connector), or 100BaseSFP Click here for info on available modules. Gigabit EthernetSlot 4 for 2 or 4-port PM-7200 Gigabit Ethernet combo module, 10/100/1000BaseT(X) or 1000BaseSFPClick here for info on available modules.ConsoleRS-232 (RJ45) Alarm Contact1 relay output with current carrying capacity of 3 A @ 30 VDC or 3 A @ 240 VAC System LED IndicatorsSTAT, PWR1, PWR2, FAULT, MASTER, COUPLER Module LED IndicatorsLNK/ACT, FDX/HDX, RING PORT, COUPLER PORT, SPEED ? Power Requirements: Input Voltage? 24 VDC (18 to 36 V) ? 48 VDC (36 to 72 V) ? 110/220 VDC/VAC (88 to 300 VDC, 85 to 264 VAC) Input Current(all ports are equipped with fiber) ? Max. 2.58 A @ 24 VDC ? Max. 1.21 A @ 48 VDC ? Max. 0.64/0.33 A @ 110/220 VDC ? Max. 0.53/0.28 A @ 110/220 VAC Overload Current ProtectionPresent Connection10-pin terminal block Reverse Polarity ProtectionPresent ? Physical Characteristics: HousingIP30 protection Weight 5900 g Dimensions440 x 44 x 325 mm (17.32 x 1.73 x 12.80 in) Installation19" rack mounting ? Agency Approvals: EMIFCC Part 15, CISPR (EN55022) class A SafetyUL60950-1, CSA C22.2 No. 60950-1, EN60950-1 (Pending) MaritimeDNV (Pending), GL (Pending) Traffic ControlNEMA TS2 (Pending) Rail TrafficEN50155/EN50121-4 Power AutomationIEC 61850-3, IEEE 1613 ? Environmental Limits: Operating Temperature-40 to 85°C (-40 to 185°F), cold start requires min. of 100 VAC at -40°C Storage Temperature-40 to 85°C (-40 to 185°F) Ambient Relative Humidity5 to 95% (non-condensing) ? Warranty Warranty Period5 years DetailsSee www.moxa.com/warranty
