WGWS/GWS Series Lavatory Service Truck

Negotiable
China
No.16, Huanghe Street, Huancui District, Weihai City, Shandong Province, China (264200)
+86 631 3803235
Online Contact
Favorite
Product Introduction

Guangtai Aircraft Lavatory Service Vehicles are designed to empty the waste from aircrafts and refill flushing water to aircraft inboard lavatories. These models can be used for all available civil aircrafts.

Safety

  • The hydraulic cylinder for lifting platform is equipped with hydraulic lock;
  • Emergency hydraulic valve to lower the lifting platform;
  • Emergency stop switch to shut down the engine;
  • Proximity switch on the platform to avoid damaging aircraft fuselage.

APPLICABLE

Applicable to all known civil aviation aircraft types.

Product Parameters

MAIN CONFIGURATION

  WGWS30 WGWS40 GWS50
Chassis JMC/ISUZU ISUZU MAN
Water Pump Stainless Steel Centrifugal Pump
Water Tank Stainless Steel Tank

OPTIONAL

Vacuum System, Winterization Kit, Flowmeter, Rear Lifting Platform, Reversing Camera, Reversing Radar, Driving Recorder Telemetry

PARAMETERS

  WGWS30 WGWS40 GWS50
Water Tank Capacity 1,000 L 1,200 L 1,500 L
Waste Tank Capacity 1,600 L 2,800 L 3,500 L
Flow Rate 170 L/min 170 L/min 170 L/min
Supplying Pressure 0.25 - 0.345 MPa 0.25 - 0.345 MPa 0.25 - 0.345 MPa
Min. Turning Radius 6,800 mm 7,50 mm 8,950 mm
Platform Lifting Height 400 - 3,000 mm 400 - 3,000 mm 400 - 3,000 mm
Weight 3,600 kg 3,950 kg 6,000 kg
