Dual-Boom Computerized Rock Drilling Jumbo WD632

Negotiable

Hunan Wuxin Intelligent Equipment Group Co., Ltd.

Located Region:

China

Address:

No. 18-1, Panpan Road, Changsha Economic and Technological Development Zone, Changsha County, Changsha City, Hunan Province

Biz Consulting:

19918865108

E-mail:

info@wuxinuniroc.com

Online Contact

Favorite

Precise

Equipped with a fully computerized control system, automatic positioning and automatic drilling, precise control of feed beam angle and hole depth, minimal overbreak

Convenient

Complex hydraulic hoses are eliminated, facilitating routine maintenance

Stable

Adaptive pressure during drilling, automatic anti-jamming reduces drilling tool consumption and lowers parts cost

Ergonomic

Liftable enclosed cab, wide field of view, high operational safety

Efficient

Equipped with hole flushing device, effectively removes rock debris from holes, improving drilling efficiency

◎ Machine Parameters
Dimensions	mm	16350×2880×3400
Weight	kg	37500
Travel Speed	km/h	15
Max. Longitudinal Gradeability	%	26
Max. Lateral Slope	°	5
Engine Power	kW	129
Ground Clearance	mm	300
Power Type	-	Diesel travel, electric operation

◎ Working Range (W×H)
Max.	mm	15800×10000
Min.	mm	6000×6000

◎ Uniroc Rock Drill
Model	-	U1838ME	U2238ME (optional)
Drilling Diameter	mm	38-89	38-89
Rated Impact Power	kW	18	22
Max. Impact Pressure	bar	230	250
Max. Rotation Torque	Nm	1000	1000

◎ Air Supply System
Working Flow	m³/min	1.08
Working Pressure	bar	8
Air Compressor Power	kW	7.5

◎ Water Supply System
Working Flow	m³/h	12
Working Pressure	bar	12~16
Water Pump Power	kW	7.5

◎ Electrical System
Total Installed Power	kW	125
Working Voltage/Frequency	V / Hz	380 / 50
Cable Length	m	80

◎ Working Platform
Working Range (W×H)	mm	16500×11600
Max. Lifting Capacity	kg	500
Telescopic Stroke	mm	5000

◎ Feed Beam
Model	-	Type A Standard	Type B Optional	Type C Optional
Drill Rod Length	mm	4915	5525	4305
Feed Beam Length	mm	6506	7136	5872
Max. Drilling Depth	mm	4640	5250	4030

▶ Dual-Boom Computerized Rock Drilling Jumbo Configuration List
Note: "●" Standard / "○" Optional / "-" Not Equipped
Product Name Model	Dual-Boom Rock Drilling Jumbo WD632 (L0)	Dual-Boom Computerized Rock Drilling Jumbo WD632 (L1)	Dual-Boom Computerized Rock Drilling Jumbo WD632 (L2)
Carrier Positioning Function	-	●	●
Drilling Plan Visualization	-	●	●
Automatic Positioning and Drilling	-	-	●
3D Profile Scanning	-	-	●
Intelligent Angle Function	-	●	●
Measurement-While-Drilling Data Acquisition	-	●	●
Drilling Log	-	●	●
Data Storage and Upload	-	●	●
MWD Geological Analysis	-	-	●
Fault Voice Alarm Function	●	●	●
Fault Self-Diagnosis Function	-	-	●
Anti-Collision Warning Function	-	-	●
Personnel Intrusion Protection Function	-	-	●
Maintenance Platform Boom	○	○	○
Remote Control System	-	-	○
Rod Adding Device	○	○	○
▶ Dual-boom series rock drilling jumbos can be equipped with a wireless remote control upon special request
