Features
Megawatt-level Charging: Single gun rated at 1500A, dual guns rated at 1800A.
Safety Protection: Triple-layer safety protection technology, providing comprehensive and multi-dimensional active protection.
User-Friendly Experience: Equipped with a high-brightness screen, ensuring clear visibility under strong light.
Easy Transportation: Supports forklift and hoist transportation, facilitating mine site relocation.
| Basic Information | Application Scenario | Mining Truck Fast Recharging Scenario |
| Power Rating | 1840 kW | |
| User Interface | Startup Method | Card Swipe (RFID), Screen Start |
| Network | Connection Method | 4G, Ethernet |
| Safety Functions | Protection Features | Input Over/Under Voltage Protection, Input Overcurrent Protection, Output Overvoltage Protection, Output Overcurrent Protection, Output Short Circuit Protection, Overtemperature Protection, Lightning Protection, Battery Reverse Connection Protection, etc. |
| Input Parameters | AC Input Current | Total Current for 8 Inputs: 2824A |
| AC Input Voltage | 380VAC ± 15% | |
| Output Parameters | Output Voltage Range | 200 ~ 1000m |
| Constant Power Output Voltage Range | 300 ~ 1000m | |
| Output Current | Max 1500A per Gun, 1800A for Dual Guns | |
| Number of Output Channels | 2 Channels | |
| Power Factor | ≥ 0.99 | |
| Total Harmonic Current | ≤ 5% | |
| Voltage Regulation Accuracy | ≤ ± 0.5% | |
| Current Regulation Accuracy | ≤ ± 1% | |
| Maximum Efficiency at Full Load | ≥ 95.5% | |
| Standards & Regulations | Applicable Standards | GB/T 18487.1-2023; GB/T 18487.2-2017; NB/T 33001-2018; NB/T 33008.1-2018; GB/T 20234.1-2023, etc. |
| Meter Accuracy Class | Class 1.0 | |
| Operating Environment | Temperature & Humidity | Operating Temperature: -40°C ~ 55°C (Derating above 55°C) Storage Temperature: -40°C ~ 70°C; Humidity: 5%-95% Non-Condensing |
| Altitude | ≤ 2000 meters | |
| Structural Characteristics | Structure & Installation | Intelligent Air Cooling, Floor-Mounted Installation |
| IP Rating | IP54 |
