Functional Features
High-power Multi-gun Coordination: Supports simultaneous/parallel/sequential charging with up to four guns. Single gun maximum output current up to 300A (800kW version), meeting the fast charging needs of multiple vehicles.
High Efficiency and Energy Saving: Peak efficiency ≥97%, power factor ≥0.99, harmonic <5%, no additional compensation required.
Wide Voltage Output Range: 200V~1000VDC, compatible with electric vehicles of different voltage platforms.
| Name | Technical Parameters | ||
| Power/kW | 640kW | 720kW | 800kW |
| AC Input Current/A | 2*491A | 2*552A | 2*613A |
| AC Input Voltage | 380VAC±15% | ||
| AC Input Frequency | 55±10Hz | ||
| Output Voltage Range | 200V ~ 1000V | ||
| Constant Power Output Voltage Range | 300V ~ 1000V | ||
| Max. Output Current per Gun/A | 250A | 300A | |
| THDi | <5% | ||
| PF | >0.99 | ||
| Peak Efficiency | ≥97% | ||
| Charging Gun Length | 5m/7m/9m/12m etc. (Customizable) | ||
| Auxiliary Power (for vehicle BMS) | 12VDC/10A compatible with 24VDC/5A (Switchable) | ||
| Residual Current Protection Rated Operating Current | 30mA | ||
| Electricity Meter Accuracy Class | Class 1.0 | ||
| DC Insulation Monitoring | Activation Condition R < 100Ω/V | ||
| Protection Rating | IP55 | ||
| Cooling Method | Intelligent Air Cooling | ||
| MTBF | ≥8760h | ||
| Connector Mechanical Operation Life | ≥10000 cycles | ||
| Product Compliance Technical Standards | GB/T 18487.1-2023; GB/T 20234.1-2023; GB/T 20234.3-2023; NB/T33008.1-2018; NB/T 33001-2018; GB/T 27930-2015; GB/T18487.2-2017; GB/T 29318-2012 etc. | ||
