Specifications
| Basic Information | Application Scenario | Heavy-duty truck operation & Trunk line logistics & Supporting battery swap station |
| Power | 400kW | |
| User Interface | Status Indicator | LED, 7-inch display |
| Start-up Method | Scan code (APP), Card swipe (RFID), VIN code, Screen start, Remote start | |
| Network | Connection Method | 4G, Ethernet |
| Safety Features | Protection Features | Input over/under voltage protection, Input overcurrent protection, Output overvoltage protection, Output overcurrent protection, Output short circuit protection, Overtemperature protection, Lightning protection, Battery reverse connection protection, etc. |
| Input Parameters | AC Input Current | 614A |
| AC Input Voltage | 380VAC±15% | |
| Output Parameters | Output Voltage Range | 150V~1000V |
| Constant Power Output Voltage Range | 300V~1000V | |
| Output Current | Dual-gun 600A (Rated), 800A (max) | |
| Power Factor | ≥0.99 | |
| Total Harmonic Current | ≤5% | |
| Peak Efficiency | ≥97% | |
| BMS Auxiliary Power | 12V/24VDC | |
| Standards & Regulations | Compliance Standards | GB/T 18487.1-2023; GB/T 18487.2-2017; NB/T 33001-2018; NB/T 33008.1-2018; GB/T 20234.1-2023; GB 39752-2024; GB 44263-2024, etc. |
| Electric Meter Accuracy Class | Class 1.0 | |
| Operating Environment | Temperature & Humidity | Operating Temperature: -30℃~60℃ (>55℃ derating) Storage Temperature: -40℃~70℃; Humidity: 5%~95% non-condensing |
| Altitude | ≤2000m | |
| Structural Features | Product Dimensions (L*W*H) | 750mm*800mm*1700mm |
| IP Rating | IP55 | |
| Charging Interface | 2 | |
| Installation Method | Floor-standing installation | |
| Cooling Method | Intelligent air cooling |
